FuelSystem
Maintenance
DANGER
Incertainconditions,fuelisextremely
ammableandhighlyexplosive.Areor
explosionfromfuelcanburnyouandothers
andcandamageproperty.
RefertoFuelSafety(page19)foracomplete
listoffuelrelatedprecautions.
DrainingtheWater
Separator
ServiceInterval:Every50hours
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Opentherearaccesscover;refertoOpening
theRear-AccessCover(page31)
4.Removetherearscreen;refertoRemovingthe
RearScreen(page31)
5.Placeacontainerunderthewaterseparator.
6.Disconnectthewireharnessfromthewater
separator(Figure57).
g264250
Figure57
1.Waterseparator3.Drainvalve
2.Switch
7.Unscrewtheswitchfrombottomofthelter
canisterandallowthewatertodrain(Figure57).
8.Installtheswitch(Figure57).
9.Connectthewireharnesstotheswitch(Figure
57).
10.Installtherearscreenandtightentheknobsand
boltstosecureit.
11.Closetherear-accesscoverandinstallthe
fastenertosecureit.
12.Bleedthefuelsystem;refertoBleedingtheFuel
System(page38).
ReplacingtheWater
SeparatorFilter
ServiceInterval:Every500hours
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,andlowertheloaderarms.
2.Shutofftheengineandremovethekey.
3.Opentherearaccesscover;refertoOpening
theRear-AccessCover(page31).
4.Removetherearscreen;refertoRemovingthe
RearScreen(page31).
5.Disconnectthewireharnessfromthewater
separator.
6.Unscrewtheswitchanddrainthewater
separator(Figure57).
7.Cleantheareawheretheltermounts.
8.Removethelterandcleanthemounting
surface.
9.Lubricatethegasketonthelterwithcleanoil.
10.Installthelterbyhanduntilthegasketcontacts
themountingsurface;thenrotateanadditional
1/2turn.
11.Installtheswitchtothelter.
12.Connectthewireharnesstotheswitch.
13.Installtherearscreenandtightentheknobsand
bolts.
14.Closetherear-accesscoverandinstallthe
fastener.
37
