•Allowsincreasedgroundspeedinheavyconditions.
•ThispositionissimilartothebenetsoftheToro
SFSmower.
Figure34
PositioningtheSeat
Theseatcanmoveforwardandbackward.Positionthe
seatwhereyouhavethebestcontrolofthemachine
andaremostcomfortable.
Toadjust,movetheleversidewaystounlockseat
(Figure35).
G008962
Figure35
UnlatchingtheSeat
Figure36
1.Seatlatch2.Seat
UsingtheDriveWheelRelease
Valves
WARNING
Handsmaybecomeentangledintherotatingdrive
componentsbelowtheenginedeck,whichcould
resultinseriousinjury.
Stoptheengine,removethekey,andallowall
movingpartstostopbeforeaccessingthedrive
wheelreleasevalves.
WARNING
Theengineandhydraulicdriveunitscanbecome
veryhot.Touchingahotengineorhydraulicdrive
unitscancausesevereburns.
Allowtheengineandhydraulicdriveunitsto
coolcompletelybeforeaccessingthedrivewheel
releasevalves.
Thedrivewheelreleasevalvesarelocatedinthebackof
eachhydraulicdriveunit,undertheseat.
Note:Makesurethereleasevalvesareinthefully
horizontalpositionwhenoperatingthemachineor
severedamagetothehydraulicsystemcanoccur.
1.DisengagethePTO(bladecontrolswitch)andturn
theignitionkeytooff.Movetheleverstoneutral
lockedpositionandapplyparkingbrake.Remove
thekey.
2.Rotatethereleasevalveleversverticallytopushthe
machine.Thisallowshydraulicoiltoby-passthe
pumpenablingthewheelstoturn(Figure37).
3.Disengageparkingbrakebeforepushing.
26
