ControlsSystem
Maintenance
AdjustingtheControlHandle
Position
Therearetwoheightpositionsforthecontrollevers;
highandlow.Removetheboltstoadjusttheheightfor
theoperator.
1.DisengagethePTO,movethemotioncontrollevers
totheneutrallockedposition,andsettheparking
brake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Loosentheboltsandangenutsinstalledinthe
levers(
Figure78).
4.Aligntheleversfronttorearpositionbybringthe
leverstogethertotheneutralpositionandslide
themuntiltheyarealigned,thentightenthebolts
(Figure79).
Figure78
1.Bolt
3.Controllever
2.Handle4.Nut
Figure79
5.Iftheendsofthelevershitagainsteachother,refer
toAdjustingtheMotionControlNeutralLockPivot.
Repeattoadjustthecontrollevers.
AdjustingtheMotionControl
Linkage
Locatedoneithersideofthefueltank,belowtheseatare
thepumpcontrollinkages.Rotatingthepumplinkage
witha1/2inchwrenchallowsnetuningadjustments
sothatthemachinedoesnotmoveinneutral.Any
adjustmentsshouldbemadeforneutralpositioningonly.
WARNING
Enginemustberunninganddrivewheelsmust
beturningsomotioncontroladjustmentcanbe
performed.Contactwithmovingpartsorhot
surfacesmaycausepersonalinjury.
Keepngers,hands,andclothingclearofrotating
componentsandhotsurfaces.
1.Priortostartingtheengine,pushthedeckliftpedal
andremovetheheightofcutpin.Lowerdeckto
theground.
2.Raisetherearofmachineupandsupportwithjack
stands(orequivalentsupport)justhighenoughto
allowdrivewheelstoturnfreely.
3.Removetheelectricalconnectionfromtheseat
safetyswitch,locatedunderthebottomcushionof
theseat.Theswitchisapartoftheseatassembly.
51
