CAUTION
Ifyouleavethekeyintheignitionswitch,someonecouldaccidentlystarttheengineandseriouslyinjure
youorotherbystanders.
Removethekeyfromtheignitionbeforeyoudoanymaintenance.
Lubrication
GreasingandLubrication
Greasemorefrequentlywhenoperatingconditionsare
extremelydustyorsandy.
GreaseType:No.2generalpurposelithiumbaseor
molybdenumbasegrease
HowtoGrease
1.Disengagethebladecontrolswitch(PTO),movethe
motioncontrolleverstotheneutrallockedposition
andsettheparkingbrake.
2.Stoptheengine,removethekey,andwaitforall
movingpartstostopbeforeleavingtheoperating
position.
3.Cleanthegreasettingswitharag.Makesureto
scrapeanypaintoffthefrontofthetting(s).
4.Connectagreaseguntothetting.Pumpgrease
intothettingsuntilgreasebeginstooozeoutof
thebearings.
5.Wipeupanyexcessgrease.
WheretoAddLightOilorSpray
Lubrication
ServiceInterval:Every100hours
Every200hours
•Brakehandlepivot.
•Deckliftpivots.
G012431
Figure40
WheretoGreasetheMower
ServiceInterval:Every50hours—Greasethemower
deckspindlesandidlerarm.
Yearly—Greasethepumpbeltidler
arm.
Yearly—Greasethefrontcaster
pivots(moreoftenindirtyordusty
conditions).
Yearly—Repackthefrontcaster
wheelbearings(moreoftenindirty
ordustyconditions).
Important:Makesurecuttingunitspindlesare
fullofgreaseweekly.
1.Disengagethebladecontrolswitch(PTO),movethe
motioncontrolleverstotheneutrallockedposition,
andsettheparkingbrake.
31
