g020489
Figure58
1.Parkingbrake4.Verticalspringassembly
2.Steeringlever
5.Nut
3.Speed-controllever6.6to7cm(2.35to2.85
inches)
8.Adjustthelinkagelengthwiththe2nutsatthe
bottomoftheverticalspringassembly(Figure
59).
Note:Thelinkageshouldmeasure22.7to23.3
cm(8.92to9.16inches).
g020525
Figure59
1.22.7to23.3cm(8.92to
9.16inches)
2.Nuts
9.Engageanddisengagethebrakestocheckfor
properengagementanddisengagement.Adjust
ifnecessary.
Note:Whenthebrakesaredisengaged,there
shouldbelittletonofreeplayinthebrake
linkagewithnodragginginthebrakes.
48
