Figure78
1.Springanchorpinunderconsole
2.Securespringswithawasherandhairpincotter
3.Slidethespringontothespring-anchorpin
5.Removethespringfromthespringanchor.
Repeatforothersideofthemachine.
6.Unlatchthemowerdeckfromtheraisedposition
andslowlylowerthemowerdecktoground;
refertoLoweringtheMowerDecktothe
OperatingPosition(page16).
Note:Themowerdeckbecomesheavierwhen
youremovethespringsfromtheanchors.Lower
themowerdeckcarefully.
7.Removethelynchpinsatthefrontofthepush
armsonbothsidesofthemachine(Figure79).
g233982
Figure79
1.Pusharm
2.Lynchpin
3.Push-armtube
8.Loosentheboltsattachedtotherubberguard
(Figure80).
g036545
Figure80
1.Bolts
2.Rubberguard
9.Unlatchtheseatanddisconnectthedriveshaft
usingthequickcoupleratthejackshaft(Figure
81).RefertoUnlatchingtheSeat(page19)
60
