Toshiba DP5022-SDM User Manual

Station Wiring, Loop Length, Telephone Power Factors
Toshiba DP5000-Series Digital Telephones
11 of 20
Station Loop Length for CIX100, CIX200, CIX670.
In a single site installation, the telephones must be placed within the allowed maximum distance of the
Base Cabinet and optional Expansion Cabinets as shown in the table below. Two-pair wiring is required to
achieve maximum range. BDKS and BWDKU cards do not provide the power wire pair. When these cards
are the station interface, the maximum loop length is shown in the one pair column.
Note When the system is powered by a backup battery, range may be less as the back up battery is
discharged.
Station Loop Lengths
CIX100, CIX200 and CIX670 Station Wiring Loop Length
Model
Maximum line length
(24 AWG)
1 Pair
1
1
BWDKU and BDKS do not support two pair wiring, one-pair wiring must be used.
2 Pair
DP5008, DP5018-S
DP5022-SDM, DP5022-SD, DP5122-SD, DP5032-SD,
DP5132-SD, DP5130-SDL
1000 ft.
(303m)
1000 ft.
(303m)
DP5018-S
DP5022-SDM, DP5022-SD,
DP5122-SD, DP5032-SD
DP5132-SD, DP5130-SDL
with DOCA1A for OCA
1000 ft.
(303m)
1000 ft.
(303m)
DP5018-S
DP5022-SDM, DP5022-SD,
DP5122-SD, DP5032-SD,
DP5132-SD, DP5130-SDL
with 1ADM
(LM5110, KM5020)
675 ft. (204m)
1000 ft.
(303m)
DP5018-S
DP5022-SDM, DP5022-SD,
DP5122-SD, DP5032-SD,
DP5132-SD, DP5130-SDL
with 2ADM
(LM5110, KM5020)
500 ft. (151m)
1000 ft.
(303m)
DP5018-S
DP5022-SDM, DP5022-SD,
DP5122-SD, DP5032-SD,
DP5132-SD, DP5130-SDL
with 1ADM
(LM5110, KM5020)+DOCA1A
675 ft. (204m)
1000 ft.
(303m)
DP5018-S
DP5022-SDM, DP5022-SD,
DP5122-SD, DP5032-SD,
DP5132-SD, DP5130-SDL
with 2ADM
(LM5110, KM5020) + DOCA1A
500 ft. (151m)
1000 ft.
(303m)
DDM5060
1000 ft.
(303m)
N/A
