User’s Manual 2-5
The Grand Tour
Backside
The following figure shows the computer's back panel.
The backside of the computer
Modem Jack The modem jack allows you to use a modular
cable to connect the modem directly to a
telephone line. (Depends on the model you
purchased.)
■ In case of a lightning storm, unplug the
modem cable from the telephone jack.
■ Do not connect the modem to a digital
telephone line. A digital line will damage the
modem.
FM Antenna Jack A jack enables the connection of FM antenna.
(Depends on the model you purchased.)
Emergency Eject
Hole
In the event that the disc drive becomes
inexplicably locked or stops responding press
this button to force a manual ejection of the ODD
tray.
DC IN 19V Jack The AC adaptor connects to this socket. Use
only the model of AC adaptor that comes with the
computer. Using the wrong adaptor can damage
your computer.
