Troubleshooting
Sanitary
(Continued)
Trouble Please check
Ref.
Page
The CLEAN indicator
does not light up
●
Is the setting "OFF"?
➞
Set to "ON".
●
If the CLEAN indicator does not light up, it is time for parts replacement.
Consult with us (See the contact information on the back cover).
48
Back
cover
Others
Trouble Please check
Ref.
Page
Water is leaking
from the plumbing
connections
●
If any nuts in a connection are loose, fi rmly tighten them with a tool such as a
monkey wrench.
➞
If the water leak does not stop, close the shutoff valve and seek repair.
-
The display on the
remote control goes
out
●
The display goes out when no button on the remote control is pressed for 5
minutes or more.
14
The main unit is
unstable
●
There is clearance between the toilet seat cushion and the toilet bowl for
activating the seat switch. When you sit on the toilet seat, the toilet seat
subsides slightly to activate the seat switch.
11
The main unit makes
a sound
<When the toilet seat is occupied>
●
You hear an operation sound at intervals of a few seconds when the cleaning
feature is working properly.
<When moving away from the toilet bowl after use>
●
You hear the sound of the remaining water being drained from the inside of
the product.
●
You may hear the fan ventilating the unit. (About 30 minutes)
<When not using the product>
●
When the cleaning feature is not used for about 8 hours, you may hear the
sound of auto wand cleaning.
-
20
[POWER] (orange)
and [ENERGY SAVER]
(orange) LEDs on
product main body are
blinking
●
If the [POWER] (orange) and [ENERGY SAVER] (orange) LEDs blink at the
same time, it is time to perform Descaling mode.
➞
Please peroform Descaling mode.
34
Specifi cations
Item
TCF403REG/RESW
TCF403REG V1
TCF403RG/RSW
Rated power supply AC 220 - 240V, 50Hz
Rated power consumption 845 - 855W
Maximum power consumption 1528 W (When the water supply temperature is (0 °C))
Type Instantaneous
Power cord length 0.82m 0.6m 1.2m
Water protection level IPX4
Functions
Cleansing
Spray
volume
Rear cleansing Approx. 0.27L to 0.43L/min.
Rear soft
cleansing
Approx. 0.27L to 0.43L/min.
Front cleansing Approx. 0.29L to 0.43L/min.
Water temperature Adjustable temperature range: OFF, about 30°C to 40°C
Heater capacity 1200 - 1428W
Safety device Temperature fuse
Backfl ow prevention device Vacuum breaker, Air gap according to EN1717
Warm air
dryer
Warm air temperature * Adjustable temperature range : About 35°C to 55°C
Airfl ow volume Approx. 0.29m
3
/min.
Heater capacity 200 - 238W
Safety device Temperature fuse
Heated
seat
Surface temperature
Adjustable temperature range: OFF, about 28°C to 36°C
(About 26°C when auto energy saver is in operation)
Heater capacity 55 - 65W
Safety device Temperature fuse
Deodorizer
Method 0
2
deodorization
Airfl ow volume Approx. 0.16 m
3
/min.
Power consumption Approx. 5.3W
Water supply pressure
Minimum required water pressure: 0.1MPa (dynamic),
Maximum required water pressure: 1.0MPa (static)
Water supply temperature 0°C to 35°C
Working ambient temperature 0°C to 40°C
Dimensions W 392mm x D 575mm x H 134mm
Weight About 7kg
* Temperature around the warm air outlet measured by TOTO.
●
When disposing of this product, please follow your local or state guidelines for proper disposal.
Reference
