Gap between the Main Unit and the Toilet Lid (Approximately once a month)
The toilet lid can be removed for thorough
cleaning.
Soft cloth soaked in water Toilet paper, etc.
(May cause damage.)
1
Unplug the power
plug.
Removing and Reinstalling
A
B
C
D
E
Hold with both
hands
Recess
Hinge
Hinge
Pin
2
Remove the toilet lid.
: Pull the left side outward.
: Disconnect the hinge from the
recess and pull up.
: Disconnect the right side.
3
Wipe with a soft cloth that
has been soaked in water
and wrung-out thoroughly.
4
Reinstall the toilet lid.
:
Join the pin and the hinge on the right side.
Slightly tilt the toilet lid to the front.
: While pulling out the left side,
:
Mount by joining the hinge with the recess.
* Be careful not to pinch your fi ngers.
5
Open and close the toilet lid
to check the mounting, and
then mount the main unit.
6
Insert the power plug.
The POWER LED lights up.
Maintenance
To Next Page
