Toyota BT Levio LWE160 User Manual

Technical information
Product guide – BT Levio W-series
60
Pallets and pallet sizes
Euro pallet
●Outer dimensions:
800 × 1200 mm
●Pallet height: 144 mm
●Height, fork entries: 100 all four sides
●Corners: 45°
●Pallet weight: approximately
27 kg
●Nominal dynamic load capacity: 1000 kg
●Nominal static load capacity: 1500 kg
●Other outer dimensions available: 600 × 800 mm.
Chep pallet (UK version)
●Outer dimensions:
1000 × 1200 mm
●Pallet height: 162 mm
●Height, fork entries:
120 mm short side handling
95 mm long side handling
●Corners: 45°
●Pallet weight: approximately
31 kg
●Nominal dynamic load capacity:
1250 kg
●Nominal static load capacity: 1750 kg
1200
800
145
100 100
145
145
145
144 100
100
910
600
382,5
227,5
382,5
227,5
1200
1000
800
880
160
100
350
350
160
100
100
100
95
120
390 390
