Toyota BT Levio LWE160 User Manual

Technical information
Product guide – BT Levio W-series
61
Choosing the optimal fork specication
When forks suited for a pallet or a specic roll container, these items should be
considered:
● The b
5
measurement must suit the pallet /roll container to enable positioning of
the forks between the pallet legs or between the wheels of the roll container.
Example: With Width over Forks 450 mm and Fork Width 180 mm, only 90 mm
remains between the forks and the truck will not be able to handle Euro pallets or
Chep pallets.
It is very important to clarify which load carriers will be used in the application and
whether they will be handled long side or short side.
Handling of roll containers 700 mm x 800 mm (L x W)
Recommended fork specications Number of roll containers
FL 1450 mm 2
FL 2150 mm 3
Application for different fork lengths
LWE180/LWE200/LWE250
Euro pallet Chep pallet
Fork length
T U Long side Short side Long side Short side
measurement 1 pallet 2 pallets 1 pallet 2 pallets 1 pallet 2 pallets 1 pallet 2 pallets
800 310 490
+
850 310 540
■
900 310 590
■
950 310 640
■ +
1000 310 690
■ +
1050 310 740
■ ■
1070 310 760
■ ■
1100 310 790
■ ■
1150 310 840
= + ■ +
1200 310 890
= + ■ +
1220 310 910
= = ■ ■
1450 310 1140
= = = ■
1550 630 920
= = ■ ■
2000 310 1690
= = = = + =
2150 780 1370
= + = = + =
2350 780 1570
= = = + = = +
+
Specially designed for this application.
= Can be used for this application.
■ Can be used for this application providing the bogie wheel is positioned between bottom boards.
