Toyota TNS 200 User Manual

RAV4 (RHD) - 13 05-01
RAV4 (A2) TNS 200
1. Remove the battery cover to dis-
connect the battery.
: Clip (1x)
: Clip (5x)
103
102
6
Fig. 1
12
Fig. 2
3. Remove the passenger’s seat .
:
Bolt (4x)
105
4
Fig. 3
100
105
6
VEHICLE DISASSEMBLY
103
102
103
2. Remove the front door scuff plate (L)
.
: Hook (3 door:12x / 5 door:8x)
100
12
4
