RAV4 (RHD) - 2605-01
RAV4 (A2) TNS 200
POST-INSTALLATION INSPECTION
Installation Check
1. Inspect the wiring and installation for abnormalities.
2. Check particularly closely for any locations where the vehicle harness, wire harness or divergency harness is being pushed,
pulled or pinched with excessive force. Also check again that clamps and bands have not shifted out of position and that all
parts have been tightened.
Operation Check
1. Attach the (-) terminal of the battery and turn the key to the ACC or ON position or start the engine.
2. Press the NAVI switch and confirm that the navigation screen is displayed.
3. Adjust the volume by following the section on ”Adjusting the Volume of the Guide Voice” in the TNS 200 Owner’s Manual, and
confirm that the sound from the speakers changes.
4. Perform the “auto-compensation” procedure by following the section on “When Tires are Replaced” in the TNS 200 Owner’s
Manual.
When an abnormality is suspected, perform troubleshooting based on the “Toyota Genuine Navigation System Service Manual”.
To Next Page
