TP-Link AC1200 User Manual

14
Chapter 4
Set Up Internet Connection
5 ) If you choose PPTP, enter the Username and Password, and choose the IP
Address Type
provided by your ISP. Different parameters are needed according
to the IP Address Type you have chosen.
5. Click Save.
6. To check your internet connection, click Network Map on the left of the page. After
the connection succeeds, the screen will display as follows. Here we take PPPoE as
an example.

TP-Link AC1200 Specifications

General

Type	-
Windows operating systems supported	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100/1000Base-T(X)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK
Wi-Fi data rate (max)	867 Mbit/s
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 30 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Ethernet LAN (RJ-45) ports	1
Power consumption (typical)	9 W
Antennas quantity	3
Antenna gain level (max)	3 dBi
Sustainability certificates	RoHS

Weight and Dimensions

Depth	125 mm
Width	202 mm
Height	86 mm
