TP-Link Archer AX20 User Manual

98
Chapter 14
Manage the Router
The figure below indicates the proper connection between the router and the Yahoo
server (www.Yahoo.com) tested through
Traceroute.
14. 9. Set Up System Time
System time is the time displayed while the router is running. The system time you
configure here will be used for other time-based functions like Parental Controls. You
can choose the way to obtain the system time as needed.
1. Visit
http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
2. Go to
Advanced > System > Time & Language.
• To get time from the internet:
1. Enable
24-Hour Time if you want the time to display in a 24-hour way.
2. In the
Set Time field, select Get from Internet.
3. Select your local Time Zone from the drop-down list.
4. In the
NTP Server I field, enter the IP address or domain name of your desired NTP
Server.

TP-Link Archer AX20 Specifications

General

Color	black
Wi-Fi Speed	1.8 gigabits per second
Wi-Fi Mesh System	no
Band Technology	dual
Frequency Band	2.4 ghz, 5.0 ghz
Beamforming	yes
QoS Traffic Prioritization	yes
Ethernet Standard	10/100/1000
Wireless Networking Standard	wi-fi 6
Wireless Standard	ax, ac, n
2.4 Ghz Streams	1
5.0 Ghz Streams	1
Antennas	4
Parental Control	yes
Firewall	nat
Data Encryption	yes
Encryption Type	wpa, wpa2, wpa3
Ports	rj-45
LAN Ports	4
WAN Ports	1
Input/Output	mu-mimo (multi-user multiple-input multiple output)
Built In Modem	no
Bluetooth	no
Smart Applications	true, tether
System Requirements	microsoft windows 98se/nt/2000/xp/vista™/7/8/8.1/10, mac os, netware, unix or linux
Smart Functions	amazon alexa

Weight and Dimensions

Height	5.3 inches
Width	1.5 inches
Net Weight	0.97 pounds
