TP-Link Archer AX20 User Manual

4
Chapter 2
Get to Know About Your Router
2. 1. Product Overview
TP-Link AX router, with next-generation 802.11ax Wi-Fi Technology, achieves Wi-
Fi performance at its ultimate level. The revolutionary combination of OFDMA and
1024QAM improve throughput by 4 times and dramatically increase the whole network
capacity and efficiency. It’s also backwards compatible with 802.11a/b/g/n/ac.
Moreover, it is simple and convenient to set up and use the TP-Link router due to its
intuitive web interface and the powerful Tether app.
2. 2. Appearance
2. 2. 1. Top Panel
The router’s LEDs (view from left to right) are located on the front. You can check the
router’s working status by following the LED Explanation table.
LED Explanation
LED Status Indication
(Power)
On The system has started up successfully.
Flashing
The system is starting up or the firmware is being upgraded. Do
not disconnect or power off your router.
Off Power is off.
(2.4GHz Wireless)
On The 2.4GHz wireless band is enabled.
Off The 2.4GHz wireless band is disabled.

TP-Link Archer AX20 Specifications

General

Color	black
Wi-Fi Speed	1.8 gigabits per second
Wi-Fi Mesh System	no
Band Technology	dual
Frequency Band	2.4 ghz, 5.0 ghz
Beamforming	yes
QoS Traffic Prioritization	yes
Ethernet Standard	10/100/1000
Wireless Networking Standard	wi-fi 6
Wireless Standard	ax, ac, n
2.4 Ghz Streams	1
5.0 Ghz Streams	1
Antennas	4
Parental Control	yes
Firewall	nat
Data Encryption	yes
Encryption Type	wpa, wpa2, wpa3
Ports	rj-45
LAN Ports	4
WAN Ports	1
Input/Output	mu-mimo (multi-user multiple-input multiple output)
Built In Modem	no
Bluetooth	no
Smart Applications	true, tether
System Requirements	microsoft windows 98se/nt/2000/xp/vista™/7/8/8.1/10, mac os, netware, unix or linux
Smart Functions	amazon alexa

Weight and Dimensions

Height	5.3 inches
Width	1.5 inches
Net Weight	0.97 pounds
