TP-Link Archer AX20 User Manual

31
Chapter 7
USB Settings
7. 1. Access the USB Storage Device
Insert your USB storage device into the router’s USB port and then access files stored
there locally or remotely.
Tips:
• If you use USB hubs, make sure no more than 4 devices are connected to the router.
• If the USB storage device requires using bundled external power, make sure the external power has been connected.
• If you use a USB hard drive, make sure its file system is FAT32, exFat, NTFS or HFS+.
• Before you physically disconnect a USB device from the router, safely remove it to avoid data damage: Go to Advanced
> USB > USB Storage Device and click Remove.
7. 1. 1. Access the USB Device Locally
Insert your USB storage device into the router’s USB port and then refer to the following
table to access files stored on your USB storage device.
Windows
computer
• Method 1:
Go to
Computer > Network, then click the Network Server Name (TP-
SHARE
by default) in the Computer section.
Note:
Operations in different systems are similar. Here we take Windows 7 as an example.

TP-Link Archer AX20 Specifications

General

Color	black
Wi-Fi Speed	1.8 gigabits per second
Wi-Fi Mesh System	no
Band Technology	dual
Frequency Band	2.4 ghz, 5.0 ghz
Beamforming	yes
QoS Traffic Prioritization	yes
Ethernet Standard	10/100/1000
Wireless Networking Standard	wi-fi 6
Wireless Standard	ax, ac, n
2.4 Ghz Streams	1
5.0 Ghz Streams	1
Antennas	4
Parental Control	yes
Firewall	nat
Data Encryption	yes
Encryption Type	wpa, wpa2, wpa3
Ports	rj-45
LAN Ports	4
WAN Ports	1
Input/Output	mu-mimo (multi-user multiple-input multiple output)
Built In Modem	no
Bluetooth	no
Smart Applications	true, tether
System Requirements	microsoft windows 98se/nt/2000/xp/vista™/7/8/8.1/10, mac os, netware, unix or linux
Smart Functions	amazon alexa

Weight and Dimensions

Height	5.3 inches
Width	1.5 inches
Net Weight	0.97 pounds
