104
Chapter 15
Manage the Router
15. 5. Local Management
This feature allows you to limit the number of client devices on your LAN from accessing
the router by using the MAC address-based authentication.
1. Visit http://tplinkwifi.net, and log in with your TP-Link ID or the password you set for
the router.
2. Go to Advanced > System > Administration and complete the settings In Local
Management section as needed.
Access the router via HTTPS and HTTP:
Tick the Enable box of Local Management via HTTPS to access the router via HTTPS
and HTTP, or keep it disabled to access the router only via HTTP.
Allow all LAN connected devices to manage the router:
Select All Devices for Local Managers.
Allow specific devices to manage the router:
1. Select All Devices for Local Managers and click SAVE.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TP-Link Archer AX95 and is the answer not in the manual?

TP-Link Archer AX95 Specifications

General IconGeneral
DSL WANNo
Ethernet WANYes
WAN connection typeRJ-45
Wi-Fi bandTri-band (2.4 GHz / 5 GHz / 5 GHz)
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN data transfer rate (max)7800 Mbit/s
WLAN data transfer rate (first band)574 Mbit/s
WLAN data transfer rate (third band)4804 Mbit/s
WLAN data transfer rate (second band)2402 Mbit/s
Product typeTabletop router
Product colorBlack
VPN serverOpenVPN, PPTP, L2TP
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000, 2500 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Number of guest networks (5 GHz)3
Number of guest networks (2.4 GHz)1
Antennas quantity8
Processor cores4
Processor frequency1700 MHz
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewall securitySPI Firewall
Security algorithmsWPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3
Package typeBox
Number of products included1 pc(s)
Power source typeDC
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Weight and Dimensions IconWeight and Dimensions
Depth183.9 mm
Width277.3 mm
Height57.3 mm
