TP-Link Archer AX95 User Manual

5
Chapter 1
Get to Know About Your Router
Status Indication
Solid blue The router is working normally.
Pulsing blue
The firmware is being upgraded, WPS connection is being established, or
the router is being reset. Do not disconnect or power off your router.
Off Power is off or the LED is turned off.
1. 2. 2. Back Panel and Side Panel
The following parts (view from left to right) are located on the back panel.
Button and Port Explanation
Item Description
USB 2.0 Port For connecting your USB storage devices to the router.
Power Port For connecting the router to a power socket via the provided power adapter.
Power On/Off Button Press this button to power on or off the router.
Reset Button
Press and hold the button until the LED blinks to reset the router to its factory
default settings.
2.5 Gbps WAN/LAN
Port*
For connecting to your modem, the Ethernet outlet or other internet devices.
Used as the WAN or LAN port.
1 Gbps WAN/LAN Port*
For connecting to your modem, the Ethernet outlet or other internet devices.
Used as the WAN or LAN port.
LAN Port (1-3) For connecting your PC or other wired devices to the router.
Note:
The 2.5 Gbps WAN/LAN port and 1 Gbps WAN/LAN port cannot be used as the WAN port at the same time. If you choose
to use 2.5 Gbps WAN/LAN port as the WAN port for internet service, the 1 Gbps WAN/LAN port will be used as LAN port
by default. It’s recommended to use 2.5 Gbps WAN/LAN port as the WAN port.

TP-Link Archer AX95 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Top Wi-Fi standard	Wi-Fi 6 (802.11ax)
WLAN data transfer rate (max)	7800 Mbit/s
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (third band)	4804 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s
Product type	Tabletop router
Product color	Black
VPN server	OpenVPN, PPTP, L2TP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000, 2500 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (5 GHz)	3
Number of guest networks (2.4 GHz)	1
Antennas quantity	8
Processor cores	4
Processor frequency	1700 MHz
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewall security	SPI Firewall
Security algorithms	WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3
Package type	Box
Number of products included	1 pc(s)
Power source type	DC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	183.9 mm
Width	277.3 mm
Height	57.3 mm
