6
Chapter 1
Get to Know About Your Router
Item Description
LED Button Press the button for 1 second to turn on or off the LEDs of your router.
WPS Button
Press the button for 1 second, and immediately initiate WPS on your client
device to start the WPS process.
Wi-Fi Button
Press and hold the button for more than 2 seconds to turn on or off the
wireless function of your router.
Reset Button
Press and hold the button for about 6 seconds until the Power LED blinks to
reset the router to its factory default settings.
LAN Port (1-4) For connecting your PC or other wired devices to the router.
WAN Port For connecting to a modem or an Ethernet outlet.
Power On/Off Button Press this button to power on or off the router.
Power Port For connecting the router to a power socket via the provided power adapter.
1. 2. 3. Side Panel
The following part is located on the side panel.
Item Description
USB 3.0 Port For connecting a USB storage device to the router.
