TP-Link Archer AXE75 User Manual

Chapter 4
Set Up Internet Connection
This chapter introduces how to connect your router to the internet. The router is
equipped with a web-based Quick Setup wizard. It has necessary ISP information built
in, automates many of the steps and verifies that those steps have been successfully
completed. Furthermore, you can also set up an IPv6 connection if your ISP provides
IPv6 service.
It contains the following sections:
• Use Quick Setup Wizard
• Quick Setup Via TP-Link Tether App
• Manually Set Up Your Internet Connection
• Set Up the Router as an Access Point
• Set Up an IPv6 Internet Connection

TP-Link Archer AXE75 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-45
3G/4G USB modem compatibility	-
VPN server	OpenVPN Server
VPN support	OpenVPN Server PPTP VPN Server L2TP VPN Server
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11n
Ethernet LAN data rates	2500 Mbit/s
Ethernet interface type	2.5 Gigabit Ethernet
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	1
Ethernet LAN (RJ-45) ports	5
IPv4 & IPv6 features	Dual stack IPv4/IPv6
Supported network protocols	IPv4, IPv6
Firewall security	SPI Firewall
Input current	2.5 A
Output voltage	12 V
Power source type	DC
Product type	Tabletop router
Product color	Black
LED indicators	Power, WAN, WLAN
Transmit power	FCC: ≤29dBm (2.4 GHz), ≤28dBm (5 GHz), ≤22dBm (6 GHz) CE: ≤17dBm (2.4 GHz), ≤27dBm (5 GHz), ≤20dBm (6 GHz) dBmW
Antennas quantity	6
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	5400 Mbit/s
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s
Processor cores	4
Processor frequency	1700 MHz
Cables included	LAN (RJ-45)
Package depth	265 mm
Package width	328 mm
Package height	120 mm
Package weight	1530 g
Number of products included	1 pc(s)
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990
Sustainability certificates	Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	147.2 mm
Width	272.5 mm
Height	49.2 mm
