TP-Link Archer AXE75 User Manual

38
Chapter 8
USB Settings
8. 1. Access the USB Storage Device
Insert your USB storage device into the router’s USB port and then access files stored
there locally or remotely.
Tips:
• If you use USB hubs, make sure no more than 4 devices are connected to the router.
• If the USB storage device requires using bundled external power, make sure the external power has been connected.
• If you use a USB hard drive, make sure its file system is FAT32, exFat, NTFS or HFS+.
• Before you physically disconnect a USB device from the router, safely remove it to avoid data damage: Go to Advanced
> USB > USB Storage Device and click Remove.
8. 1. 1. Access the USB Device Locally
Insert your USB storage device into the router’s USB port and then refer to the following
table to access files stored on your USB storage device.
Windows
computer
• Method 1:
Go to Computer > Network, then click the Network Server Name (TP-
SHARE by default) in the Computer section.
Note:
Operations in different systems are similar. Here we take Windows 7 as an example.

TP-Link Archer AXE75 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-45
3G/4G USB modem compatibility	-
VPN server	OpenVPN Server
VPN support	OpenVPN Server PPTP VPN Server L2TP VPN Server
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11n
Ethernet LAN data rates	2500 Mbit/s
Ethernet interface type	2.5 Gigabit Ethernet
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	1
Ethernet LAN (RJ-45) ports	5
IPv4 & IPv6 features	Dual stack IPv4/IPv6
Supported network protocols	IPv4, IPv6
Firewall security	SPI Firewall
Input current	2.5 A
Output voltage	12 V
Power source type	DC
Product type	Tabletop router
Product color	Black
LED indicators	Power, WAN, WLAN
Transmit power	FCC: ≤29dBm (2.4 GHz), ≤28dBm (5 GHz), ≤22dBm (6 GHz) CE: ≤17dBm (2.4 GHz), ≤27dBm (5 GHz), ≤20dBm (6 GHz) dBmW
Antennas quantity	6
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	5400 Mbit/s
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s
Processor cores	4
Processor frequency	1700 MHz
Cables included	LAN (RJ-45)
Package depth	265 mm
Package width	328 mm
Package height	120 mm
Package weight	1530 g
Number of products included	1 pc(s)
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990
Sustainability certificates	Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	147.2 mm
Width	272.5 mm
Height	49.2 mm
