TP-Link Archer AXE75 User Manual

4
Chapter 1
Get to Know About Your Router
1. 1. Product Overview
TP-Link AXE router, with the 802.11ax Wi-Fi technology and the brand-new 6 GHz
band, achieves Wi-Fi performance at its ultimate level. The revolutionary combination
of OFDMA and 1024QAM improve throughput by 4 times and dramatically increase
capacity and efficiency of the whole network. Access to the 6 GHz band brings more
bandwidth, faster speeds, and lower latency, opening up resources for future innovations
like in AR/VR, 8K streaming and more.
Moreover, it is simple and convenient to set up and use the TP-Link router due to its
intuitive Tether app and the powerful web interface.
1. 2. Appearance
1. 2. 1. Top Panel
The router’s LEDs (view from left to right) are located on the front. You can check the
router’s working status by following the LED Explanation table.
LED Explanation
Name Status Indication
(Power)
On The system has started up successfully.
Flashing
The system is starting up or the firmware is being upgraded. Do
not disconnect or power off your router.
Off Power is off.

TP-Link Archer AXE75 Specifications

General

Ethernet WAN	Yes
SIM card slot	No
WAN connection type	RJ-45
3G/4G USB modem compatibility	-
VPN server	OpenVPN Server
VPN support	OpenVPN Server PPTP VPN Server L2TP VPN Server
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11n
Ethernet LAN data rates	2500 Mbit/s
Ethernet interface type	2.5 Gigabit Ethernet
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	1
Ethernet LAN (RJ-45) ports	5
IPv4 & IPv6 features	Dual stack IPv4/IPv6
Supported network protocols	IPv4, IPv6
Firewall security	SPI Firewall
Input current	2.5 A
Output voltage	12 V
Power source type	DC
Product type	Tabletop router
Product color	Black
LED indicators	Power, WAN, WLAN
Transmit power	FCC: ≤29dBm (2.4 GHz), ≤28dBm (5 GHz), ≤22dBm (6 GHz) CE: ≤17dBm (2.4 GHz), ≤27dBm (5 GHz), ≤20dBm (6 GHz) dBmW
Antennas quantity	6
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
WLAN data transfer rate (max)	5400 Mbit/s
WLAN data transfer rate (first band)	574 Mbit/s
WLAN data transfer rate (second band)	2402 Mbit/s
Processor cores	4
Processor frequency	1700 MHz
Cables included	LAN (RJ-45)
Package depth	265 mm
Package width	328 mm
Package height	120 mm
Package weight	1530 g
Number of products included	1 pc(s)
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990
Sustainability certificates	Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	147.2 mm
Width	272.5 mm
Height	49.2 mm
