TP-Link HC220-G5 User Manual

43
Chapter 11 NAT Forwarding
11. 2. Share Local Resources over the Internet by
Virtual Server
When you build up a server in the local network and want to share it on the internet,
Virtual Server can realize the service and provide it to the internet users. At the same
time virtual server can keep the local network safe as other services are still invisible
from the internet.
Virtual server can be used for setting up public services in your local network, such as
HTTP, FTP, DNS, POP3/SMTP and Telnet. Different service uses different service port.
Port 80 is used in HTTP service, port 21 in FTP service, port 25 in SMTP service and
port 110 in POP3 service. Please verify the service port number before configuration.
Share my personal website I’ve built in a local network with my
friends through the internet.
For example, the personal website has been built on my home
PC (192.168.0.100). I hope that my friends can visit my website.
The PC is connected to the controller with the WAN IP address
218.18.232.154.
Controller
WAN: 218.18.232.154
LAN
Home
Personal Website
1. Assign a static IP address to your PC, for example
192.168.0.100.
2. Visit http://tplinkwifi.net, and log in with the password you
set for the controller.
3. Go to Advanced > NAT Forwarding > Virtual Servers, click
Add.
I want to:
How can I
do that?

TP-Link HC220-G5 Specifications

General

Antenna type	Internal
Product type	Mesh system
Certification	CE, FCC
Product color	White
LED indicators	Yes
Transmit power	30 dBmW
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Apps supported	TP-Link Tether
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	SSID, WMM, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3
Networking standards	IEEE 802.11k, IEEE 802.11r, IEEE 802.11v
WLAN data transfer rate (max)	1200 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Mobile network generation	Not supported
Operating modes	Router Mode, Access Point Mode
Processor cores	2
Firewall security	SPI
NAT functionality	IPTV, IGMPV2/3 and IGMP Snooping
Processor frequency	0.88 GHz
Transmitting power (CE)	20 dBm
Transmitting power (FCC)	30 dBm
Mobile operating systems supported	Android, iOS
Supported network protocols (IPv6)	IPv4 IPv6
Ethernet LAN (RJ-45) ports	3
AC adapter input current	1 A
AC adapter input voltage	12 V
Sustainability certificates	CE, Federal Communications Commission (FCC)
Number of products included	1 pc(s)

Weight and Dimensions

Width	100 mm
Height	89.5 mm
