TP-Link HC220-G5 User Manual

Chapter 12
VPN Server
The VPN (Virtual Private Networking) Server allows you to access your home network in
a secured way through internet when you are out of home. The router offers two ways
to setup VPN connection: OpenVPN and PPTP (Point to Point Tunneling Protocol) VPN.
OpenVPN is somewhat complex but with greater security and more stable. It is suitable
for restricted environment, such as campus network and company intranet.
PPTP VPN is more easily used and its speed is faster, it’s compatible with most operating
systems and also supports mobile devices. Its security is poor and your packets may
be cracked easily, and PPTP VPN connection may be prevented by some ISP.
This chapter contains the following sections, you can choose the appropriate VPN
server connection type as needed.
• Use OpenVPN to Access Your Home Network
• Use PPTP VPN to Access Your Home Network

TP-Link HC220-G5 Specifications

General

Antenna type	Internal
Product type	Mesh system
Certification	CE, FCC
Product color	White
LED indicators	Yes
Transmit power	30 dBmW
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Apps supported	TP-Link Tether
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Security algorithms	SSID, WMM, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK, WPA3
Networking standards	IEEE 802.11k, IEEE 802.11r, IEEE 802.11v
WLAN data transfer rate (max)	1200 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Mobile network generation	Not supported
Operating modes	Router Mode, Access Point Mode
Processor cores	2
Firewall security	SPI
NAT functionality	IPTV, IGMPV2/3 and IGMP Snooping
Processor frequency	0.88 GHz
Transmitting power (CE)	20 dBm
Transmitting power (FCC)	30 dBm
Mobile operating systems supported	Android, iOS
Supported network protocols (IPv6)	IPv4 IPv6
Ethernet LAN (RJ-45) ports	3
AC adapter input current	1 A
AC adapter input voltage	12 V
Sustainability certificates	CE, Federal Communications Commission (FCC)
Number of products included	1 pc(s)

Weight and Dimensions

Width	100 mm
Height	89.5 mm

Summary

About This Guide

Conventions

Explains symbols and formatting used in the guide.

More Info

Provides links for additional resources like support and specifications.

Get to Know Your Device

Product Overview

Describes the purpose and function of the mesh Wi-Fi AP system.

Appearance

Details the physical components and indicators of the device.

Connect the Device

Position the Device

Provides guidelines for optimal placement of the device for best performance.

Connect Your Device

Outlines the steps to connect the device to your network.

Log In to Your Device

Login Procedure

Explains how to access the device's web management page for configuration.

Set Up Internet Connection

Use Quick Setup Wizard

Guides users through an automated process for internet setup.

Configure the Device in Router Mode

Details how to set up the device for router functionality.

Create Mesh Wi-Fi System

Add Agent to Network

Explains how to add an agent to extend the mesh network coverage.

Multi-SSID

Create Multi-SSID Network

Describes how to set up multiple wireless networks for different purposes.

TP-Link Cloud Service

Register a TP-Link ID

Guides on creating a TP-Link ID for cloud management.

Change Your TP-Link ID Information

Explains how to update account details for the TP-Link ID.

Manage the User TP-Link IDs

Covers adding and removing user accounts for router management.

Manage the Router via the TP-Link Tether App

Details using the mobile app for remote router management.

EasyMesh with Seamless Roaming

Set up a EasyMesh network

Provides instructions for creating a unified Wi-Fi network.

Parental Controls

Configure Parental Controls

Explains how to block websites and control access times for devices.

Network Security

Firewall & DoS Protection

Details how to protect the network from cyber attacks and DoS.

Service Filtering

Explains how to block specific services or internet access.

Access Control

Covers blocking or allowing specific devices on the network.

IP & MAC Binding

Describes binding IP to MAC addresses to prevent ARP attacks.

NAT Forwarding

Translate Address and Port by ALG

Explains Application Layer Gateway for NAT traversal.

Share Local Resources over the Internet by Virtual Server

Details setting up virtual servers to share local resources.

Open Ports Dynamically by Port Triggering

Describes how to open ports dynamically for applications.

Make Applications Free from Port Restriction by DMZ

Explains how to use DMZ for unrestricted application access.

Make Xbox Online Games Run Smoothly by UPnP

Details enabling UPnP for smooth online gaming.

VPN Server

Use OpenVPN to Access Your Home Network

Guides on setting up OpenVPN for secure remote access.

Use PPTP VPN to Access Your Home Network

Explains how to set up PPTP VPN for remote access.

Customize Your Network Settings

Change LAN Settings

Covers modifications to the local area network configuration.

Configure IPv6 LAN Settings

Details how to set up IPv6 addressing for the LAN.

Set Up a Dynamic DNS Service Account

Explains how to configure DDNS for remote access.

Create Static Routes

Guides on defining static routes for network traffic.

Set Up the IPv6 Tunnel

Details configuring IPv6 tunnel services.

Specify Wireless Settings

Covers adjusting wireless network configurations.

Use WPS for Wireless Connection

Explains how to use WPS for easy wireless setup.
