TP-Link MC110CS User Manual

 Connectors: RJ-45, SC.
 Network Cables: Cat.5 Twisted-Pair (below abbreviated as
TP), 9/125um Single-mode fiber and 50/125, 62.5/125um
Multi-mode fiber.
Model NO. Interface
Transmission
Distance
Transmission
Media
Output Center
Wavelength
MC100CM RJ45--SC 2km
Multi-mode
Fiber, TP
1310nm
MC110CS RJ45--SC 20km
Single-mode
Fiber, TP
1310nm
MC111CS RJ45--SC 20km
Single-mode
Fiber, TP
1550nmTX
1310nmRX
MC112CS RJ45--SC 20km
Single-mode
Fiber, TP
1310nmTX
1550nmRX
1.5 Appearance Indication
1.5.1 LED Indicators
The converter has LED indicators which can provide a real-time
report. When you take a look at these indicators, you will know what’s
happening on your network. For details, please refer to the table as
shown below.
4

TP-Link MC110CS Specifications

General

I/O ports	1x 100M SC 1x 100M RJ45
Full duplex	Yes
Dimensions (WxDxH)	94.5 x 73 x 27 mm
Fiber optic connector	SC
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Cabling technology	UTP 3, 4, 5e, 5
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Ethernet interface type	Gigabit Ethernet
Maximum data transfer rate	1000 Mbit/s
Fiber ethernet cabling technology	100BASE-FX
Internal	No
Certification	FCC, CE
Product color	Black
LED indicators	Power, Speed
Wavelength	1310 nm
Maximum transfer distance	20000 m
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Power consumption (max)	1.52 W
Package depth	204 mm
Package width	165 mm
Package height	65 mm
Package weight	380 g

Weight and Dimensions

Depth	73 mm
Width	94.5 mm
Height	27 mm
