TP-Link Omada EAP115 Specifications

General

5 GHz	No
2.4 GHz	Yes
Frequency band	2.4 - 2.4835 GHz
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	300M: -71dBm@10% PER 150M: -75dBm@10% PER 54M: -78dBm@10% PER 11M: -93dBm@8% PER 6M: -92dBm@10% PER 1M: -96dBm@8% PER
Virtual LAN features	VLAN mapping
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Transmitting power (CE)	19 dBm
Transmitting power (FCC)	21 dBm
Maximum data transfer rate	300 Mbit/s
WAN connection	Ethernet (RJ-45), Wi-Fi
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Ceiling, Wall
Certification	CE, FCC, RoHS
Product color	White
Cable lock slot type	Kensington
Output current	1 A
Output voltage	12 V
Power consumption (typical)	5 W
Power over Ethernet (PoE) type supported	Passive PoE
Antenna type	Internal
Antenna features	Integrated antenna
Antennas quantity	2
Antenna direction type	Omni-directional
Antenna gain level (max)	3 dBi
Number of products included	1 pc(s)
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, HTTPS, SNMP, SSH, WPA, WPA-PSK, WPA2-Enterprise, WPA2-PSK
Number of SSID supported	8
Service Set Identifier (SSID) features	Multiple SSIDs
Minimum system requirements	Microsoft Windows 10/8/7/Vista/XP
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	268 mm
Package width	246 mm
Package height	69 mm
Package weight	600 g
Harmonized System (HS) code	85176990
Sustainability certificates	Federal Communications Commission (FCC), CE, RoHS

Weight and Dimensions

Depth	180 mm
Height	47.5 mm
