TP-Link Omada OC200 User Manual

107
3. The following page will appear. Configure this SSID as “guest_2.4GHz“, keep the
Security Mode as “None” and check the box to enable the Portal feature for this SSID.
Click OK.
4. Click to enter the configuration page for the 5GHz band. Similarly to
the configurations for the 2.4GHz band, configure another SSID for the guests on the
5GHz band.
Configure Portal Authentication
Follow the steps below to configure portal authentication:
1. Go to the Wireless > Portal page.

TP-Link Omada OC200 Specifications

General

Networking standards	IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100 Mbit/s
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Input current	1 A
DC input voltage	5 V
Power over Ethernet (PoE)	Yes
Power consumption (typical)	5 W
Flash memory	4000 MB
Internal memory	1024 MB
Processor frequency	1000 MHz
Control display unit	No
Internal memory type	DDR3
Management platform	L3
Security algorithms	SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CE, FCC, RoHS
Product color	Black
Cables included	LAN (RJ-45)
Compatible operating systems	Windows10, 8, 7, Vista, XP; MAC OS; NetWare, UNIX; Linux
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	128 mm
Package width	135 mm
Package height	70 mm
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	98 mm
Width	99.8 mm
Height	25 mm
