TP-Link Omada OC200 User Manual

53
Connection
Threshold/Difference
Threshold
Connection Threshold defines the maximum number of clients
connected to the 5GHz band. The value of Connection Threshold
is from 2 to 40, and the default is 20.
Difference Threshold defines the maximum difference between
the number of clients on the 5GHz band and 2.4GHz band. The
value of Difference Threshold is from 1 to 8, and the default is 4.
When the following two conditions are both met, the EAP prefer to
refuse the connection request on 5GHz band and no longer steer
other clients to the 5GHz band:
1.The number of clients on the 5GHz band reaches the Connection
Threshold value.
2.The difference between the number of clients on the 2.4GHz
band and 5GHz band reaches the Difference Threshold value.
Max Failures If a client repeatedly attempts to associate with the EAP on the
5GHz band and the number of rejections reaches the value of Max
Failures, the EAP will accept the request.
The value is from 0 to 100, and the default is 10.
3. Click Save.

TP-Link Omada OC200 Specifications

General

Networking standards	IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates	10, 100 Mbit/s
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Input current	1 A
DC input voltage	5 V
Power over Ethernet (PoE)	Yes
Power consumption (typical)	5 W
Flash memory	4000 MB
Internal memory	1024 MB
Processor frequency	1000 MHz
Control display unit	No
Internal memory type	DDR3
Management platform	L3
Security algorithms	SSID, WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CE, FCC, RoHS
Product color	Black
Cables included	LAN (RJ-45)
Compatible operating systems	Windows10, 8, 7, Vista, XP; MAC OS; NetWare, UNIX; Linux
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	128 mm
Package width	135 mm
Package height	70 mm
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	98 mm
Width	99.8 mm
Height	25 mm
