10 SSP-PRC001-EN
Table 1. General Data — Heat Pumps
7½ Tons 10 Tons 15 Tons 20 Tons
Single Compressor
TWA090A3,A4,AW
Single Compressor
TWA120A3,A4,AW
Dual Compressor
TWA180B3,B4,BW
Dual Compressor
TWA240B3,B4,BW
Cooling Performance
(i)
(i)
Cooling Performance is rated at 95°F ambient, 80°F entering dry bulb, 67°F entering wet bulb. Gross capacity does not include the effect of fan motor
heat. ARI capacity is net and includes the effect of fan motor heat. Certified in accordance with the Unitary Large Equipment certification program,
which is based on ARI Standard 340/360-00.
Gross Cooling Capacity
Matched Air Handler 91,000 124,000 182,000 240,000
Matched Heat Pump Only
(ii)
(ii)
Condensing unit only gross cooling capacity rated at 45°F saturated suction temperature and at 95°F ambient.
91,000 124,000 182,000 240,000
ARI Net Cooling Capacity
(iii)
(iii)
ARI net cooling capacity is calculated with matched blower coil and 25 feet of 1 3/8" or 1/2" OD interconnecting tubing.
89,000 120,000 176,000 234,000
EER
(iv)
(iv)
EER is rated at ARI conditions and in accordance with DOE test procedures.
Matched Air Handler 10.1 10.1 9.9 9.3
Heat Pump Only 11.5 11.1 10.9 10.3
Integrated Part Load Value
(v)
(v)
Integrated part load value is based on ARI Standard 340/360-00. Units are rated at 80°F ambient, 80°F entering dry bulb (DB), and 67°F entering
wet bulb (WB) at ARI rated cfm.
- - 11.0 10.5
System/Condensing Unit Power (kW) 8.70/7.95 11.91/11.07 17.77/16.62 24.99/23.20
Heating Performance
ARI Heating and Matched Air Handler
High Temperature Capacity 87,000 122,000 168,000 234,000
System kW/COP 7.68/3.3 10.82/3.2 16.10/3.1 22.42/3.1
Low Temperature Capacity 55,000 80,000 106,000 154,000
System kW/COP 6.73/2.4 9.62/2.4 14.16/2.2 19.54/2.30
Compressor
No./Type 1/Trane 3-D
TM
Scroll 1/Trane 3-D
TM
Scroll 2/Trane 3-D
TM
Scroll 2/Trane 3-D
TM
Scroll
No. Motors/HP 1/7.5 1/10 2/7.5 2/10
Motor RPM 3450 3450 3450 3450
Sound Rating (BELS)
(vi)
(vi)
Sound rating shown is tested in accordance with ARI Standard 270 or 370.
8.8 8.8 8.8 8.8
System Data
(vii)
(vii)
Refer to refrigerant piping applications manual for line sizing and line length.
No. Refrigerant Circuits 1 1 2 2
Suction Line (in.) OD 1 3/8 1 3/8 1 3/8 1 3/8
Liquid Line (in.) OD 1/2 1/2 1/2 1/2
Outdoor Coil - Type Plate Fin Plate Fin Plate Fin Plate Fin
Tube Size (in.) OD .375 .375 .375 .375
Face Area (sq ft) 19.2 29.5 38.5 50.2
Rows/FPI 2/18 2/18 2/18 2/18
Refrigerant Control Expansion Valve Expansion Valve Expansion Valve Expansion Valve
Outdoor Fan - Type Propeller Propeller Propeller Propeller
No. Used/Diameter (in.) 1/26 1/28 2/26 2/28
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1 Direct1
CFM 5890 8200 11,780 16,240
No. Motor/HP 1/.50 1/1.00 2/.50 2/1.00
Motor RPM 1100 1100 1100 1100
Refrigerant Charge (Field Supplied)
(lbs of R-22)
(viii)
(viii)
Refrigerant (operating) charge is for condensing unit (all circuits) with matching blower coils and 25 feet of interconnecting refrigerant lines. All units
are supplied with a small nitrogen holding charge only.
18.00 31.50 36.00 48.50
