SSP-PRC001-EN 29
Performance Data
Table 30. Discharge Plenum and Grille Assembly Throw Distance (ft) — Air Handler
Louver Angle Deflection Position
Tons Model No. CFM Straight 20° 40° 55°
5
1600 42 31 26 20
TWE060A 1800 46 37 29 22
TWE060B 2000 48 43 33 24
2200 51 50 36 25
2400 54 57 39 29
7½
2400 52 43 35 29
TWE090A 2700 55 48 38 31
TWE090B 3000 58 53 42 32
3300 62 57 46 35
3600 66 60 50 37
10
3200 56 46 38 30
TWE120A 3600 62 51 42 33
TWE120B 4000 66 57 47 35
4400 71 62 52 38
4800 76 67 56 42
15
4900 47 38 32 25
TWE180B 5400 52 44 37 29
6000 57 49 41 32
6600 61 53 43 34
7200 65 57 46 35
20
6400 56 46 38 30
TWE240B/ 7200 62 51 42 33
TWE240E 8000 66 57 47 35
8800 71 62 52 38
9600 76 67 56 42
Notes:
1. Throw distance values are based on a terminal velocity of 75 FPM.
2. Throw distance values at other terminal velocities may be established by multiplying throw
distances in the table above by throw factor
Terminal
Velocity
Throw
Factor
50 FPM x 1.50
100 FPM x .75
150 FPM x .50
Discharge Plenum and Grille Assembly Throw Distance
