Trane 7½ - 20 Tons User Manual

28 SSP-PRC001-EN
Performance Data
5-20 Tons Motor and Fan Speed, Electric Heat Discharge Plenum and Grille Airflow
Table 27. Standard Motor and Sheave/Fan Speed (RPM) - Air Handler
Sheave Position
Tons Unit Model No.
6 Turns
Open
5 Turns
Open
4 Turns
Open
3 Turns
Open
2 Turns
Open
1 Turns
Open Closed
5
TWE060A
(i)
(i)
Factory setting is 3.0 turns open.
- 714 773 833 892 952 1011
TWE060B
(i)
7 1/2
TWE090A
(ii)
(ii)
Factory setting is 4.5 turns open.
- 726 787 847 908 968 1029
TWE090B
(ii)
10
TWE120A1, B1
(iii)
(iii)
Factory setting is 4.0 turns open.
- 702 760 819 877 936 994
TWE120A3, AW
(ii)
- 710 761 812 863 913 964
TWE120B3, BW
(ii)
15 TWE180B
(ii)
760 795 831 866 902 937 -
20 TWE240B
(iv)
/TWE240E
(iv)
(iv)
Factory setting is 6.0 turns open.
862 894 926 958 990 1022 1054
Table 28. Oversized Motor and Sheave/Fan Speed (RPM) - Air Handler
Sheave Position
Tons Unit Model No.
6 Turns
Open
5 Turns
Open
4 Turns
Open
3 Turns
Open
2 Turns
Open
1 Turns
Open Closed
5
TWE060A1,B1 - 828 897 966 1035 1104 1173
TWE060A3,A4,AW - 863 934 1006 1078 1150 1222
TWE060B3,B4,BW
7½
TWE090A1 - 845 915 986 1056 1127 1197
TWE090A3,AW - 847 908 968 1029 1089 1150
10
TWE120A3,AW
(i)
(i)
High Static Motor with 6 1/2" Fan Sheave.
- 915 969 1023 1077 1131 1185
TWE120B3,BW
(i)
TWE120A3,AW
(ii)
(ii)
High Static Motor with 8" Fan Sheave.
- 733 776 819 863 906 949
TWE120B3,BW
(ii)
15 TWE180B 946 981 1016 1052 1087 1122 1157
20 TWE240B/TWE240E - 991 1040 1091 1140 1190 1239
Table 29. Electric Heat Discharge Plenum and Grille Airflow (CFM)
Electric Heater Airflow (CFM)
Tons Unit Model No. Model No. Minimum Maximum
5
TWE060A1, B1 BAYHTRL117A 2000 2400
TWE060A3, B3 BAYHTRL315A 2000 2400
TWE060A4, B4 BAYHTRL415A 2000 2400
7 1/2
TWE090A1, B1 BAYHTRL117A 3000 3600
BAYHTRL123A 3375 3600
TWE090A3, B3 BAYHTRL315A 2625 3600
BAYHTRL325A 3000 3600
TWE090A3, B3 BAYHTRL415A 2625 3600
BAYHTRL425A 2625 3600
10
TWE120A1, B1 BAYHTRL117A 3500 4800
BAYHTRL123A 4000 4800
TWE120A3, B3 BAYHTRL315A 4000 4800
BAYHTRL325A 3500 4800
TWE120A3, B3
(i)
(i)
When wired for 460 Volt.
BAYHTRL415A 3500 4800
BAYHTRL425A 3500 4800
15
TWE180B3 BAYHTRM330A 5250 7200
TWE180B4 BAYHTRM430A 5250 7200
20
TWE240B3/TWE240E3 BAYHTRM330A 7000 9600
TWE240B4/TWE240E4 BAYHTRM430A 7000 9600
