12 SSP-PRC001-EN
Table 3. Gross Cooling Capacities (MBh) 7½ Tons TWA090A Heat Pump with 7½ TWE090A Air Handler
CFM Air
flow
Ent
DB °F
Ambient Temperature
85 95 105
Entering WB
61 67 73 61 67 73 61 67 73
MBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHCMBHSHC
2700 75 84.1 67.2 92.8 56.3 102.1 37.7 81.2 65.7 89.5 55.0 98.5 36.4 78.0 64.2 86.1 53.6 94.8 35.2
80 84.6 78.6 93.0 64.5 102.1 49.6 81.8 77.2 89.8 63.2 98.5 48.3 78.8 75.7 86.3. 61.7 94.8 46.9
85 86.9 86.9 93.1 75.8 102.2 61.3 84.4 84.4 89.9 74.4 98.7 60.0 81.7 81.7 86.4 72.9 95.0 58.6
90 91.2 91.2 93.7 87.3 102.3 72.9 88.7 88.7 90.6 85.9 98.7 71.5 86.0 86.0 87.3 84.5 95.1 70.0
3000 75 87.5 70.3 94.4 54.8 103.7 38.4 82.7 68.8 91.1 53.4 100.0 37.1 79.4 67.2 87.5 51.9 96.1 35.7
80 86.5 82.9 94.6 67.5 103.7 51.2 83.6 81.4 91.1 65.9 100.0 499 80.5 79.9 87.6 64.4 96.2 48.5
85 89.6 89.6 94.7 79.7 103.8 64.0 87.1 87.1 91.4 78.3 100.2 62.6 84.3 84.3 87.9 76.7 96.4 61.3
90 94.1 94.1 95.7 92.4 92.4 103.9 76.4 91.5 92.5 91.0 100.3 75.0 88.6 88.6 88.7 88.7 96.5 73.6
3300 75 87.0 73.3 95.7 56.6 104.9 39.0 83.9 71.7 92.3 55.2 101.2 37.6 80.6 70.1 88.6 53.7 97.3 36.2
80 88.1 87.0 95.8 70.1 105.0 52.8 84.7 84.7 92.4 68.6 101.2 51.4 81.9 81.9 88.8 67.0 97.4 50.0
85 92.0 92.0 96.1 83.4 105.1 66.5 89.3 89.3 92.8 82.0 101.4 65.2 86.4 86.4 89.2 80.4 97.6 63.8
90 96.6 96.6 97.5 97.2 105.2 79.9 93.9 93.9 93.9 93.9 101.5 78.5 90.9 90.9 91.0 91.9 97.7 77.0
3600 75 88.2 76.1 96.8 58.3 106.0 39.5 85.0 74.6 93.3 56.9 102.2 38.1 81.6 73.0 89.6 55.4 98.2 36.7
80 89.3 89.3 96.9 72.7 106.1 54.2 86.6 86.6 93.4 71.2 102.3 52.9 83.7 83.7 89.8 69.6 98.3 51.5
85 94.1 94.1 97.4 87.0 106.2 69.0 91.3 91.3 94.0 85.6 102.5 67.6 88.3 88.3 90.4 84.0 98.4 66.1
90 98.9 98.9 98.9 98.9 106.4 83.2 96.0 96.0 96.1 96.1 102.6 81.8 92.9 92.9 93.0 93.0 98.7 80.3
CFM Air
flow
Ent
DB °F
Ambient Temperature
115
Enter WB
61 67 73
MBH SHC MBH SHC MBH SHC
2700 75 74.7 62.5 82.4 52.1 90.9 33.8
80 75.6 74.1 82.6 60.0 91.0 45.5
85 78.9 78.9 82.9 71.3 91.1 57.2
90 83.1 83.1 84.0 83.0 91.3 68.5
3000 75 75.9 65.6 83.7 50.4 92.2 34.3
80 77.0 77.0 83.9 62.8 92.3 47.1
85 81.3 81.3 84.3 75.2 92.5 59.9
90 85.6 85.6 85.7 85.7 92.6 72.1
3300 75 77.1 68.5 84.8 52.2 93.3 34.8
80 78.9 78.9 85.0 65.4 93.4 48.6
85 83.3 83.3 85.6 78.9 93.6 62.4
90 87.8 87.8 87.9 87.9 93.7 75.5
3600 75 78.1 71.3 85.7 53.9 94.1 35.3
80 80.6 80.6 85.9 68.0 94.3 50.1
85 85.1 85.1 86.7 82.5 94.4 64.6
90 89.7 89.7 89.8 89.8 94.8 78.8
Notes:
1. Dry coil condition. Total gross capacity (MBh) shown to the left is not applicable. In this case the Sensible Heat Capacity (SHC) is the total capacity.
2. All temperatures are in °F.
3. All capacities shown are gross and have not considered indoor fan heat.
4. To obtain net cooling capacities, subtract indoor fan heat.
5. MBH = Total Gross Cooling Capacity
6. SHC = Sensible Heat Capacity
Performance Data
