AC-SVX003A-EN
103
Table 30. Diagnostics — Starter (continued)
Diagnostic
Name and
Source
Affects
Target
Severity
Persistence
Active Modes
[Inactive
Modes]
Criteria
Reset
Level
Starter Fault Type
II - xy
Cprsr
Immediate Latch
Starting - All
types of starters
a. This is a specific starter test where the Shorting
Contactor (1K3) is individually energized and a check is
made to ensure that there are no currents detected by the
CT's. If current is detected when only S is energized at
Start, then 1M is shorted. b. This test in a. above applies to
all forms of starters (Note: It is understood that many
starters do not connect to the Shorting Contactor.).
Local
Starter Fault Type
III - xy
Cprsr
Immediate Latch
Starting
[Adaptive
Frequency
Starter Type]
As part of the normal start sequence to apply power to the
compressor, the Shorting Contactor (1K3) and then the
Main Contactor (1K1) were energized. 1.6 seconds later
there were no currents detected by the CT's for the last 1.2
Seconds on all three phases. The test above applies to all
forms of starters except Adaptive Frequency Drives.
Local
Starter Module
Memory Error
Type 1 - xy
Cprsr Warning
Latch All
Checksum on RAM copy of the Starter LLID configuration
failed. Configuration recalled from EEPROM.
Local
Starter Module
Memory Error
Type 2 - xy
Cprsr
Immediate Latch All
Checksum on EEPROM copy of the Starter LLID
configuration failed. Default configuration loaded into RAM
and EEPROM.
Local
Transition
Complete Input
Opened - xy
Cprsr
Immediate Latch
All Running
Modes
The Transition Complete input was found to be shorted
before the compressor was started. This is active for all
electromechanical starters.
Local
Transition
Complete Input
Shorted - xy
Cprsr
Immediate Latch Pre-Start
The Transition Complete input was found to be shorted
before the compressor was started. This is active for all
electromechanical starters.
Local
Under Voltage
Chiller Normal NonLatch
Pre-Start and
Any Ckt(s)
Energized
Nom. trip: 60 seconds at less than 87.5%, +/- 2.8% at 200V
+/- 1.8% at 575V, Auto Reset at 90% or greater for 10
continuous seconds.
Remote
Main Processor Diagnostics
Table 31. Diagnostics — main processor
Diagnostic
Name
Affects Target Severity
Persistence
Active Modes
[Inactive
Modes]
Criteria
Reset
Level
AFD Comm Loss
- xA
Cprsr
Immediate NonLatch All
Communication has been lost between the UC800 and the
applicable AFD. Once triggered, this diagnostic will auto-
reset after 10 continuous minutes of restored
communication to the compressor. (Note: The timer only
starts once communication to the compressor is restored,
which the UC800 will detect. If a manual reset request
occurs during the timer period, it shall reset the diagnostic
and the ‘auto-reset’ function will then be bypassed.)
Local
AFD Failure to
Arm or Start - xA
Cprsr
Immediate Latch
Running
The AFD failed to start within the allotted time (1 min).
Definition of the “starting” value is the running status of the
AFD. Note: This is a Controller diagnostic, not one
originating from the AFD.
