Installation Mechanical
Unit Leveling
Before snugging down the mounting bolts, level the unit carefully. Check unit level
end-to-end by using a water level, or by placing a level on the top surface of the unit
frame. Unit should be level within 1/4-inch (6.35 mm) over the length. Place the level
on the unit frame and check front to back level. Adjust to within1/4-inch (6.35 m) of
level front-to-back. Use shims to level the unit.
20 Red Red Red Red
25 Red Red Red Red
30 Red Red Red Red
40 Red Red Red Red
50 Green Green Green Green
60 Green Green Green Green
Table 6 RDP 3 Neoprene Isolator Selection
Unit Size
Location
1234
