118
RT-SVX072A-EN
Table 52. eFlex™™ staging sequence and compressor data (continued)
1 X 1800 4860
2 X X 1500 5460
3 X X X 2400 5580
50 Ton eFlex™ Variable Speed Compressor
Stage Comp 1A VZH170 Comp 2A Comp 2B
VZH
Min Spd Max Spd
1 X 1620 4200
2 X X 1500 4740
3 X X X 2340 4800
55 Ton eFlex™ Variable Speed Compressor
Stage Comp 1A VZH170 Comp 2A Comp 2B
VZH
Min Spd Max Spd
1 X 1740 4560
2 X X 1800 5280
3 X X X 2520 5280
60 Ton eFlex™ Variable Speed Compressor
Stage Comp 1A VZH170 Comp 2A Comp 2B
VZH
Min Spd Max Spd
1 X 1920 4740
2 X X 1500 5700
3 X X X 2520 5820
70 Ton eFlex™ Variable Speed Compressor
Stage Comp 1A VZH170 Comp 2A Comp 2B
VZH
Min Spd Max Spd
1 X 2220 5220
2 X X 1500 6000
3 X X X 2220 6000
75 Ton eFlex™ Variable Speed Compressor
Stage Comp 1A VZH170 Comp 1B Comp 2A Comp 2B
VZH
Min Spd Max Spd
1 X 2520 5160
2 X X 1500 4500
3 X X X 1500 5040
4 X X X X 1500 5880
Electronic Expansion Valves
All Intellipak1 with Symbio systems use electronic
expansion valves (EXV's) to control superheat. These
valves are factory set to 12°F of superheat to balance
efficiency and compressor reliability at all operating
conditions.
This setting can be adjusted through the Symbio
controller display, but this only recommended to be
done at the discretion of Trane Product Support
Pressure curves included in this document are based
on outdoor ambient between 65° & 105°F, relative
humidity above 40 percent. Measuring the operating
pressures can be meaningless outside of these ranges.
UUnniitt SSttaarrttuupp
