10
S9V2-VS-SVX001-1B-EN
Document Pack Contents S9V2-VS
Item
Qty. Description
SSAAFFEETTYY WWAARRNNIINNGG
Onlyqualified personnelshould installand servicethe equipment. Theinstallation, startingup, andservicing ofheating, ventilating,and air-conditioning
equipmentcan behazardous andrequires specificknowledge andtraining. Improperlyinstalled, adjustedor alteredequipment byan unqualifiedperson
couldresult indeath orserious injury.When workingon theequipment, observeall precautionsin theliterature andon the tags,stickers, andlabels that
areattached tothe equipment.
December 2022
SS99VV22--VVSS--SSVVXX000011--11BB--EENN
Upow/Horizontal and Dedicated Downow
Gas-Fired, Direct/Non-Direct Vent, 2-Stage
Condensing Variab
l
e Speed Furnac
e
s with Variab
l
e Speed
Draft Inducer
UUppffllooww,,CCoonnvveerrttiibbllee ttoo
HHoorriizzoonnttaallRRiigghhtt oorr
HHoorriizzoonnttaallLLeefftt
S9V2B040U3VSAE
S9V2B060U3VSAC/D
S9V2B080U4VSAC/D
S9V2C100U4VSAC/D
S9V2D120U5VSAC/D
DDoowwnnffllooww OOnnllyy
S9V2B080D4VSAC/D
S9V2C100D4VSAC/D
Graphics in this document are for representation
only. Actual model may differ in appearance.
Note:
CAUTION
!
Failure to follow this Caution could result in property damage or personal injury. 4GXC* and
4MXC* coils installed on upflow furnaces in vertical, horizontal left, or horizontal right
orientations without a factory installed metal drain pan shield must use a MAY*FERCOLKITAA
kit. Coils installed on upflow furnaces must have drain pans that are suitable for 400° F
(205°C) or have a metal drain pan shield. Downflow furnaces do not require a metal drain pan
shield or the use of the MAY*FERCOLKITAA kit.
COIL REQUIREMENT!
Instal
lation, Operation, and Maintenance
1 1
Condensate Drain Tube Assembly
2 1
Inlet Vent
(a)
3 1 Inlet Vent Gasket
4 1
Outlet Vent Assembly
5 1 Outlet Vent Gasket
6 6 Screws
7 1
Condensate Trap Grommet
8 1
Plug – Condensate/Gas
9 1
Plug – Electrical
10 2
Grommet – Condensate/Gas
11 1
Installation, Operation, and Maintenance
12 1 Owner Guide
13 1
Limited Warranty
14 1
2” to 3” Coupling – CPL00938
(b)
(a)
3” inlet vent supplied with S9V2D120U5VS only. 2” inlet vent supplied with all other models.
(b)
Supplied with S9V2D120U5VS only.
Part List
• Igniter
• Flame Sensor
• In-shot Burner(s)
• Gas Valve
• Inducer Assembly
• Blower Motor
• Blower Wheel
• IFC (Integrated Furnace Control)
• Pressure Switch(es)
• Main Thermal Limit
• Roll-Out Switch(es)
• Reverse Air Switch(es)
AAcccceessssoorriieess
