S9V2-VS-SVX001-1B-EN
11
Product Specification
Model
S9V2B040U3
VSAE
(a)
,
(b)
S9V2B060U3
VSAC/D
(a)
,
(b)
S9V2B080U4
VSAC/D
(a)
,
(b)
S9V2C100U4
VSAC/D
(a)
,
(b)
S9V2D120U5
VSAC/D
(a)
,
(b)
Type Upflow / Horizontal
RATINGS
(c)
1st Stage Input BTUH 26,000 39,000 52,000 65,000 78,000
1st Stage Capacity BTUH (ICS) 25,700 38,450 51,050 64,200 77,050
2nd Stage Input BTUH 40,000 60,000 80,000 100,000 120,000
2nd Stage Capacity BTUH (ICS)
(d)
39,350 57,700 76,700 97,150 116,250
1st Stage Temp. Rise (Min. - Max.) °F
25 - 55 25 - 55 30 - 60 25 - 55 35 - 65
2nd Stage Temp. Rise (Min. - Max.) °F
30 - 60 35 - 65 35 - 65 35 - 65 40 - 70
AFUE (%)
(d)
97.0
Return Air Temp. (Min. - Max.) °F
45°F - 80°F
BLOWER DRIVE DIRECT
Diameter - Width (in.)
11 X 8 11 X 10
No. Used 1
Speeds (No.)
Variable
CFM vs. in. w.g.
See Fan Performance Table
Motor HP
1/2 3/4
1
R.P.M. Variable
Volts / Ph / Hz 120 / 1 / 60
FLA 6.4
5.7 / 6.4 8 / 9.6 10.5 / 10
COMBUSTION FAN - Type Variable Speed
Drive - No. Speeds
Direct - Variable
Motor RPM
1/50 - 5000
Volts/Ph/Hz 33 - 110 / 3 / 60 - 180
FLA 0.77
Inducer Orifice 0.61 0.79 0.96 1.05 1.19
FILTER - Furnished? No
Type Recommended High Velocity
Hi Vel. (No.-Size-Thk.)
1 - 16 X 25 - 1 in. 1 - 20 X 25 - 1 in. 1 - 24 X 25 - 1 in.
VENT OUTLET DIA - MIN. (in.)
(e)
2 Round 3 Round
INLET AIR DIA - MIN. (in.)
(e)
2 Round 3 Round
HEAT EXCHANGER – Type
Fired 409 Stainless Steel
Unfired 29-4C Stainless Steel
Gauge (Fired)
20
ORIFICES - Main
Nat. Gas (Qty. - Drill Size)
2 - 45 3 - 45 4 - 45 5 - 45 6 - 45
Propane Gas (Qty. - Drill Size)
2 - 56 3 - 56 4 - 56 5 - 56 6 - 56
GAS VALVE
Redundant - Two Stage
PILOT SAFETY DEVICE – TYPE
120 V SiNi Igniter
BURNERS - TYPE - QTY
Inshot - 2 Inshot - 3 Inshot - 4 Inshot - 5 Inshot - 6
POWER CONN. - V/Ph/HZ
(f)
120 / 1 / 60
Ampacity (Amps)
8.9
8.1 / 8.9 10.9 / 12.9 14.1 / 13.4
Max. Overcurrent Protection (Amps)
15
PIPE CONN. SIZE (IN.)
1/2
