Trane Sintesis Balance CMAF User Manual

11UNT-PRC002-GB
Sound power levels
Discharge
Measurement conditions:
Measurements taken in a room adjacent to the room containing the FWD, at the outlet of the rectangular duct (1.5 m
long) fixed to its discharge opening.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 55 50 42 37 37 31 30 46
FWD 08 2 57 54 47 40 30 38 40 50
3 58 57 50 42 32 40 43 53
1 57 51 45 42 34 33 28 48
FWD 10 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 57 51 45 42 34 33 28 48
FWD 12 2 58 54 48 45 38 39 35 51
3 60 58 50 48 40 42 39 54
1 56 62 50 48 39 38 36 56
FWD 14 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
1 57 63 51 49 40 39 37 57
FWD 20 2 61 66 55 53 47 46 45 60
3 63 69 58 56 50 50 49 63
Intake
Measurement conditions:
Measurements taken at the horizontal air intake.
Fan Power level in dB(A), per Hz frequency band Overall power
Unit speed 125 250 500 1000 2000 4000 8000 dB(A)
1 56 55 55 53 46 45 42 57
FWD 08 2 63 62 60 60 53 53 53 64
3 66 65 63 62 56 55 57 67
1 62 58 55 58 51 48 44 61
FWD 10 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 62 58 55 58 51 48 44 61
FWD 12 2 66 63 60 62 56 55 52 66
3 70 67 63 65 59 59 57 69
1 66 65 65 65 57 50 46 68
FWD 14 2 73 72 69 71 64 59 57 74
3 78 76 73 75 69 64 63 78
1 68 72 64 64 56 52 50 69
FWD 20 2 76 76 68 71 65 61 61 75
3 78 79 71 74 69 66 66 78
CG-SVX051A-GB
11
Table 1 - General data CMAF 080-100 Standard Short Efficiency
Unit size 080 090 100
Total cooling capacity (1) kW 269 301 327
Total heating capacity (1) kW 290 323 353
Total power Input (1) kW 91 106 121
Unit Electrical Data (2) (3) (4)
Short Circuit Unit Capacity (9) kA 15 15 15
Power Cable Cross Section (max) mm² 1*240 1*240 1*240
Disconnect switch size A 400 400 500
Digit 56=1 AC fan
Max. power input kW 119 138 157
Max. Amps A 205 237 270
Unit start up amps (w/o soft starter - Digit 54=A) (4) A 419 495 527
Unit start up amps (with soft starter - Digit 54=B) (4) A 315 367 399
Displacement power factor (dpf) - 0.83 0.84 0.84
Digit 56=2 EC fan
Max. power input kW N/A N/A N/A
Max. Amps A N/A N/A N/A
Unit start up amps (w/o soft starter - Digit 54=A) (4) A N/A N/A N/A
Unit start up amps (with soft starter - Digit 54=B) (4) A N/A N/A N/A
Displacement power factor (dpf) - N/A N/A N/A
Digit 56=3 EC fan HESP
Max. power input kW N/A N/A N/A
Max. Amps A N/A N/A N/A
Unit start up amps (w/o soft starter - Digit 54=A) (4) A N/A N/A N/A
Unit start up amps (with soft starter - Digit 54=B) (4) A N/A N/A N/A
Displacement power factor (dpf) - N/A N/A N/A
Compressors
Manifold Tonnage (Ton) Circuit 1 and 2 25+25 25+30 30+30
Max Comp Power input Circuit 1 / Circuit 2 kW 56.9/56.9 66.7/66.7 76.5/76.5
Rated Amps Circuit 1 / Circuit 2 (4) A 93/93 109/109 76.5/76.5
Start Amps Circuit 1 / Circuit 2 (Digit 54=A) (4) A 307/307 367/367 125/125
Start Amps Circuit 1 / Circuit 2 (Digit 54=B) (4) A 203/203 239/239 383/383
Locked Rotor Amps Circuit 1 / Circuit 2 (4) A
260+260/
260+260
260+320/
260+320
320+320/
320+320
Motor speed rpm 2900 2900 2900
Oil sump heater Circuit 1 / Circuit 2 W 180/180 180/180 180/180
Number or refrigerant circuits - 2 2 2
Number of part load steps - 4 8 4
Minimum capacity step % 25 23 25
Dual Circuit Chilled Water Exchanger
Brazed Plate Heat Exchanger Materials (model) - Stainless Steel / Copper (DFX 650)
Plate number - 106 138 138
Water Content l 31 40.4 40.4
Nominal water connection size in 4 4 4
(Grooved coupling) - With or without HYM mm 114.3 114.3 114.3
Water Pressure Drop (1) kPa 46.8 35.7 41.5
Dual Circuit Hot Water exchanger
Brazed Plate Heat Exchanger Materials (model) - Stainless Steel / Copper (DFX 650)
Plate number - 138 166 166
Water Content l 40.4 48.6 48.6
Nominal water connection size in 4 4 4
(Grooved coupling) - With or without HYM mm 114.3 114.3 114.3
Water Pressure Drop (1) kPa 39.3 34.3 40.3
Condenser Module
Coils
Type - Aluminum / Copper Fin and Tube
Total Quantity - 6 6 6
Face area per circuit m² 7 7 7
Fans
Type - Propeller Fan: Fixed speed AC motor
Number of fans
- 6 6 6
Air ow (1), cooling mode m
3
/h 114,617 114,169 113,776
Air ow (2), heating/heat pump mode m
3
/h 113,907 114,062 114,188
Digit 56=1 AC fan
Max Power Input per Motor kW 1.4 1.4 1.4
Max Amps per Motor A 2.8 2.8 2.8
Motor RPM (Cooling mode) rpm/min 870 870 870
Digit 56=2 EC fan
Max Power Input per Motor kW N/A N/A N/A
Max Amps per Motor A N/A N/A N/A
Motor RPM (Cooling mode) rpm/min N/A N/A N/A
Digit 56=3 EC fan HESP
Max Power Input per Motor kW N/A N/A N/A
Max Amps per Motor A N/A N/A N/A
Motor RPM (Cooling mode eld setting) rpm/min N/A N/A N/A
General Data
