5
Accessory Number Description Fits Cabinet Size
BAYEAAC04BK1 Electric Heater, 4kW, Breaker, 24V Control, 1 Ph A to C
BAYEAAC04LG1 Electric Heater, 4kW, Lugs, 24V Control, 1 Ph A to C
BAYEAAC05BK1 Electric Heater, 5kW, Breaker, 24V Control, 1 Ph A to C
BAYEAAC05LG1 Electric Heater, 5kW, Lugs, 24V Control, 1 Ph A to C
BAYEAAC08BK1 Electric Heater, 8kW, Breaker, 24V Control, 1 Ph A to C
BAYEAAC08LG1 Electric Heater, 8kW, Lugs, 24V Control, 1 Ph A to C
BAYEAAC10BK1 Electric Heater, 10kW, Breaker, 24V Control, 1 Ph A to C
BAYEAAC10LG1 Electric Heater, 10kW, Lugs, 24V Control, 1 Ph A to C
BAYEAAC10LG3 Electric Heater, 10kW, Lugs, 24V Control, 3 Ph A to C
BAYEABC15BK1 Electric Heater, 15kW, Breaker, 24V Control, 1 Ph B to C
BAYEABC15LG3 Electric Heater, 15kW, Lugs, 24V Control, 3 Ph B to C
BAYEABC20BK1 Electric Heater, 20kW, Breaker, 24V Control, 1 Ph B to C
BAYEACC25BK1 Electric Heater, 25kW, Breaker, 24V Control, 1 Ph C
BAYSUPFLGAA Supply Duct Flange A A
BAYSUPFLGBA Supply Duct Flange B B
BAYSUPFLGCA Supply Duct Flange C C
BAYRETFLGAA Return Duct Flange A A
BAYRETFLGBA Return Duct Flange B B
BAYRETFLGCA Return Duct Flange C C
BAYSRKIT100A Side Return Kit A to C
BAYFLR1620A High Velocity Filter Kit, 16” X 20’ X 1” (10 filters) A
BAYFLR2020A High Velocity Filter Kit, 20” X 20’ X 1” (10 filters) B
BAYFLR2220A High Velocity Filter Kit, 22” X 20’ X 1” (10 filters) C
TASB175SB Plenum Stand with Integrated Sound Baffle A A
TASB215SB Plenum Stand with Integrated Sound Baffle B B
TASB235SB Plenum Stand with Integrated Sound Baffle C C
MITISRKIT1620 Side Return Kit with 16” x 20” Filter A to C
BAYFRKIT175 Front Return Kit for 17.5” Cabinet A
BAYFRKIT210 Front Return Kit for 21.0” Cabinet B
BAYFRKIT235 Front Return Kit for 23.5” Cabinet C
BAYBAFKT175 Sound Baffle Kit for 17.5” Cabinet A
BAYBAFKT210 Sound Baffle Kit for 21.0” Cabinet B
BAYBAFKT235 Sound Baffle Kit for 23.5” Cabinet C
TASSBK175 Sound Baffle Kit for 17.5” Cabinet A
TASSBK215 Sound Baffle Kit for 21.0” Cabinet B
TASSBK235 Sound Baffle Kit for 23.5” Cabinet C
BAYICSKIT01A Internal Condensate Switch Kit A to C
BAYHHKIT001A Horizontal Hanger Kit A to C
BAYUVCLK001A UVC Lights A to C
BAYLVKIT100A Low Voltage Conduit Entry Kit A to C
BAYSPEKT200A Single Point Power Entry Kit B to C
BAYINSKT175A
Solcoustic® Liner Kit - 17.5" Cabinet
A
BAYINSKT215A
Solcoustic® Liner Kit - 21.5" Cabinet
B
BAYINSKT235A
Solcoustic® Liner Kit - 23.5" Cabinet
C
BAYCNDPIP01A 3/4” PVC Threaded Pipe Kit Foam Seal (10 per box) A to C
Section 3. Unit Preparation
3.1 Prepare The Unit For Installation
STEP 1 - Check for damage and report promptly to
the carrier any damage found to the unit.
Note: If the unit must be transported in a horizontal
position, it must be laid on its back (marked “REAR”
on carton).
Note: After the unit is removed from the carton,
release pressure from the coil to verify coil is
pressurized and leak free.
Note: Remove the cardboard from the bottom of the
blower. Cut the tie wrap and remove the foam block
located at the motor.
Table 3.2 Unit Accessories
