Installation Guide
14 18-HD98D1-1B-EN
9. Indoor Sensor Setup
9.1 Available Sensors
A list of all available sensors for the system will be
displayed at the top of the Indoor Sensor Setup
screen. Once a sensor has been assigned, it will
be removed from the list of available sensors. The
sensors from the communicating equipment will
show up in the list automatically, but the wireless
sensors must be added one by one.
Supported Indoor Sensors:
• UX360 Thermostat (Onboard Sensor)
• SC360 System Controller (Onboard Sensor)
• Wireless Indoor Sensor (ZSENS930AW00MA)
• Wired Indoor Sensor (ZZSENSAL0400AA)
NOTE: The SC360 will only be included as
an available sensor if it has been configured
and installed in controlled space. This setting
can be modified from Technician Access >
Configuration > Climate Control > SC360
System Controller.
9.2 Sensor Details
Select a specific sensor to view more details
about the sensor and to assign it to the system.
The details displayed may be different for
different sensor types.
Sensor Details May Include:
• Assigned Status: if the sensor has been
assigned to the system or not
• Use Temperature: enables/disables the use
of the temperature sensor on the device
• Use Humidity: enables/disables the use of
the humidity sensor on the device
• Battery: battery % on battery powered
sensors
• Status: communicating status with the
system
• Serial Number: serial number of the sensor
• Model Number: model number of the
sensor
• Sensor Name: sensor name can be
changed to a default or custom name
• Temperature Weight: weight of the
temperature sensor when being averaged
with other sensors
View, edit and assign temperature and humidity sensors for the system.
