Installation Guide
2 18-HD98D1-1B-EN
Contents
1. Safety
NOTE: Use 18-gauge color-coded thermostat
cable for proper wiring. Shielded cable is not
typically required.
Keep this wiring at least one foot away from
large inductive loads such as Electronic Air
Cleaners, motors, line starters, lighting ballasts
and large distribution panels.
Failure to follow these wiring practices may
introduce electrical interference (noise) which
can cause erratic system operation.
All unused thermostat wires should be grounded
at indoor unit chassis ground only. Shielded
cable may be required if the above wiring
guidelines cannot be met. Ground only one end
of the shield to the system chassis.
This information is intended for use by
individuals possessing adequate backgrounds
of electrical and mechanical experience. Any
attempt to repair a central air conditioning
product may result in personal injury and/or
property damage. The manufacturer or seller
cannot be responsible for the interpretation of
this information, nor can it assume any liability
in connection with its use.
LIVE ELECTRICAL COMPONENTS!
During installation, testing, servicing, and
troubleshooting of this product, it may
be necessary to work with live electrical
components. Failure to follow all electrical
safety precautions when exposed to live
electrical components could result in death or
serious injury.
1. Safety ...................................................................... 2
2. Product Specifications .......................................... 3
3. General Information ............................................... 3
3.1 What’s in the Box? ......................................... 3
3.2 Accessories ................................................... 3
4. Trane
®
Link Systems .............................................. 4
5. Placement & Installation ....................................... 5
5.1 Location ........................................................ 5
5.2 Network Connections .................................... 6
5.3 Mounting ....................................................... 6
5.4 Wiring ............................................................ 6
6. Field Wiring Connection Diagram Options ......... 7
7. CAN Low Voltage Troubleshooting ...................... 8
8. Configuration ......................................................... 9
8.1 General.......................................................... 9
8.2 Climate Control ............................................. 9
8.3 Energy ......................................................... 11
8.4 Environment ................................................ 11
8.5 Accessories ................................................. 12
9. Indoor Sensor Setup ............................................ 14
9.1 Available Sensors ........................................ 14
9.2 Sensor Details ............................................. 14
9.3 Assigning Sensors ...................................... 15
9.4 Unassigning Sensors .................................. 15
9.5 Adding Wireless Sensors ............................ 15
9.6 Removing Wireless Sensors ....................... 16
10. System Operation ................................................ 17
10.1 Power-Up Sequence ................................... 17
10.2 Service Reminders ...................................... 17
10.3 Software Updates ........................................ 17
10.4 System Mode .............................................. 17
10.5 Fan Mode .................................................... 17
10.6 Air Cleaner Mode ........................................ 17
11. Test Modes ........................................................... 18
12. Equipment Summary ........................................... 18
13. Alerts ..................................................................... 19
14. Troubleshooting ................................................... 19
