Trane TTK 509 E User Manual

14 SS-SVN03B-EN
Wiring
Interconnection
Figure 10. Wiring Interconnection: MCW, “K” and “L” model, with condensing units TTK
Figure 11. Wiring Interconnection: MCW, “K” and “L” models, with condensing units TTK
NOTES:
1) Single power supply point for each unit.
(indoor unit and outdoor unit)
NOTES:
1) Single power supply point for both units.
(indoor unit and outdoor unit)
208-230V 1PH
50/60 Hz
208-230V 1PH
50/60 Hz
208-230V 1PH
50/60 Hz

Trane TTK 509 E Specifications

General

Brand	Trane
Model	TTK 509 E
Category	Heat Pump
Language	English
