Parts Identification
17
Parts Identification - Continued
Bonneville T100 (all models) and Bonneville T120 (all models)
(Bonneville T120 shown)
13
4
6
891011121314 7
52
1. Fuel tank
2. Coolant pressure cap (under fuel tank)
3. Fuel filler cap
4. Front brake fluid reservoir
5. Front brake lever
6. Front fork
7. Oil filler plug
8. Oil level sight glass
9. Rear brake pedal
10. Rear brake fluid reservoir (behind side
panel)
11. Adjustment tool (behind side panel)
12. Drive chain
13. Rear suspension unit
14. Silencer
