True TC400 User Manual

15
ASSEMBLY STEPS
STEP 1—REMOVE MOTOR COVER AND MOTOR CAP COVERS
Parts Used in this Step
PART DESCRIPTION QTY
PS0035 SCREW, M5XP0.8X15MM SCA5-15 9
TC4036LBK SUBASSEMBLY, CAP, MOTOR COVER-LH 1
TC4036RBK SUBASSEMBLY, CAP, MOTOR COVER-RH 1
TC4035BK SUBASSEMBLY, MOTOR COVER 1
Tools Used in this Step
#2 Phillips Screwdriver
PS0035
TC4036LBK
TC4036RBK
PS0035
TC4035BK
1. Using a #2 Phillips screwdriver, remove and set aside the left and right motor cover caps.
2. Using a #2 Phillips screwdriver, remove and set aside the motor cover.
