TSC MH240 Series User Manual

8
1.4 Ribbon Specifications
Ribbon outside diameter
Max. 90 mm OD
Ribbon length
600 m
Ribbon core inside diameter
1“ (25.4 mm)
Ribbon width
25.4 mm ~ 114.3 mm (1”~4.5”)
Ribbon wound type
Ink coated outside wound, ink coated inside wound
Ribbon end type
Transparency
1.5 Media Specifications
Media roll capacity
Max. 8” (203.2 mm) OD; 1.5” or 3” ID core, Rewind 3” only
Media core diameter
1” (25.4mm, for MH240 and MH240T Series only) or 1.5” (38.1 mm) or 3” (76.2 mm) ID core
Media type
Continuous, die-cut, black mark, fan-fold, notch, perforated, tag, and care label (outside wound)
Media wound type
Outside wound
Media width
20 mm ~ 114 mm (0.78“ ~ 4.49“)
Media thickness
0.06 mm ~ 0.28 mm (2.36 ~ 11 mil)
Label length
203 dpi models
300 dpi models
600 dpi models
5 mm ~ 25,400 mm (0.20” ~ 1,000”)
5 ~ 11,430 mm (0.20” ~ 450”)
5 ~ 2,540 mm (0.20” ~ 100”)
Black mark
Min. 8 mm (W) x Min. 2 mm (H)
Gap height
Min. 2 mm
