2.2.2 Interior View
1. Ribbon rewind spindle
2. Print head pressure position adjustment knob
3. Print head pressure adjustment knob
4. Print head release lever
5. Ribbon supply spindle
6. TSC website QR Code
7. Label supply spindle
8. Media near end sensor
(movable, MH240T Series only)
9. Label roll guard
10. External label entrance chute
11. Damper
12. Print head
13. Platen roller
14. Front label guide
15. Ribbon sensor
16. Black mark sensor (shown as↓)
17. Gap sensor (shown as ▽)
