TSC MH240 Series User Manual

13
2.2.3 Rear View
1. External label entrance chute
2. Slot-in Wi-Fi module (Option)
3. RS-232C interface
4. Ethernet interface
5. USB interface
6. microSD card slot
7. Centronics interface (Option)
8. Power switch
9. Power cord socket
10. GPIO interface (Option)
Note: The interface picture here is for reference only. Please refer to the product specification for the interfaces availability.
2
3
4
5
6
7
10
9
8
1
3
4
5
6
7
8
10
9
1. External label entrance chute
2. RS-232C interface
3. Ethernet interface
4. USB interface
5. microSD card slot
6. Centronics interface (Option)
7. GPIO interface (Option)
8. Slot-in Wi-Fi interface (Option)
9. Power switch
10. Power cord socket
1
2
MH240/MH240T Series
MH240P Series
