TSC TTP-244CE series User Manual

TSC AUTO ID Technology Co., Ltd. 119 Copyright 2009 All Rights Reserved.
 GOTO
Description
This command is used to branch to a specified label. The label cannot exceed 8 characters in
length.
Syntax
GOTO LABEL
:LABEL
Parameter Description
LABEL Beginning of the point. The maximum length of the label is 8
characters.
Example
DOWNLOAD "GOTO1.BAS"
SIZE 3,3
GAP 0.08,0
DENSITY 8
SPEED 4
DIRECTION 1
REFERENCE 0,0
SET CUTTER OFF
SET PEEL OFF
CLS
A=0
TOTAL=0
:START
IF A<100 THEN
GOTO SUM
ELSE
GOTO PRTOUT
ENDIF
:SUM
A=A+1
TOTAL=TOTAL+A
GOTO START
:PRTOUT
B$="THE SUMMATION OF 1..100 IS "+STR$(TOTAL)
TEXT 10,100,"3",0,1,1,B$
PRINT 1
END
EOP

TSC TTP-244CE series Specifications

General

Resolution	203 dpi
Processor	32-bit RISC CPU
Print Method	Thermal Transfer / Direct Thermal
Max Print Speed	4 inches per second
Memory	8 MB SDRAM, 4 MB Flash
Communication Interfaces	USB, Serial (RS-232)
Media Handling	Continuous, Fan-Fold
Media Type	Continuous, Die-cut, Black Mark, Fan-fold
Media Width	1 inch to 4.4 inches
Media Roll Diameter	127 mm (5 inches)
Ribbon Length	300 m
Ribbon Core	25.4 mm (1 inch)
Power	100-240 VAC, 50/60 Hz
Weight	2.5 kg
Max Print Length	2, 286 mm (90")
Dimensions	232 mm (W) x 156 mm (H) x 288 mm (D) 9.13" (W) x 6.14" (H) x 11.34" (D)
